APC Smart-UPS 1500 LCD

Mfg. Part: SMT1500RM2U|CDW Part: 2267329|UNSPSC: 39121011
  • UPS
  • Rack-mountable
  • 1500 VA power capacity
  • 7.2 min battery run time (up to)
  • 1 kW power provided
  • 120 V
  • 3 year warranty
Availability:In stock
Ships same business day if ordered before 3pm ET
Check Warehouse Availability ▼
 Close
Warehouse LocationAvailableQuantity Incoming
Inventory quantities are delayed by 15 minutes.
$745.99Advertised Price
Untitled Document
Close

Have leasing questions? Let us know how can we help.

Note: Leasing is available to businesses only. Leasing is not available to individuals.
800.972.3922
Mon-Fri 7am-7:30pm CT
Product Overview
Main Features
  • UPS
  • Rack-mountable
  • 1500 VA power capacity
  • 7.2 min battery run time (up to)
  • 1 kW power provided
  • 120 V
  • 3 year warranty
APC award-winning Smart-UPS is the most popular UPS in the world for servers, storage and networks. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today's multi-core or virtualized servers that have varying load consumption. Rack mounted Smart-UPS are ideal for powering blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery. The extended run Smart-UPS XL has the capability to add external battery packs to scale runtime from minutes to hours typically needed for converged voice and data networks.
Energy/Environment standards
ENERGY STAR Yes
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Power Supply
Device Energy Rating: 459 Joules

Battery
Load Type: At full load
Recharge Time: 3 hours
Run Time (Up To): 7 min, 7.2 min

Power Output Connectors Details
Connector Qty: 6
Connector Type: Power NEMA 5-15

Interface Provided
Connector Type: 4 pin USB Type B
Qty: 1
Type: Management (USB)
Type: USB



Type: Serial

Cable
Connectivity Details Length: 2.44 m
Connectivity Details Type: Serial cable



Connectivity Details Type: USB cable



Connectivity Details Length: 8 ft
Connectivity Details Type: Power cable

Service
Support Details Full Contract Period: 3 years
Support Details Type: Limited warranty



Support Details Full Contract Period: 2 years

Environmental Parameters
Humidity Range Operating: 0 - 95%
Max Operating Temperature: 104 °F, 40 °C
Min Operating Temperature: 0 °C, 32 °F
Sound Emission: 46 dBA

Header
Brand: APC
Compatibility: PC
Manufacturer: APC
Model: 1500 LCD , 1500VA LCD RM
Packaged Quantity: 1
Product Line: APC Smart-UPS

Miscellaneous
Color: Black
Compliant Standards: CSA , FCC Class A certified , FCC Part 15 , FCC Part 15 A , REACH , RoHS , RoHS Exemption 7b , UL 1449 , UL 1778
Equipment Protection Value: 150000 US Dollars
Height (Rack Units): 2
Product Color: Black
Rack Mounting Kit: Included

Networking
Remote Management Interface: RS-232 , USB

Power Device
Circuit Protection: Circuit breaker
Form Factor: Rack-mountable
Frequency Provided: 57 - 63 Hz
Frequency Required: 50/60 Hz
Input Connector Qty: 1
Input Connector Type: Power NEMA 5-15
Input Voltage Range: AC 82 - 144 V
Input Voltage Range (Adjustable): AC 75 - 154 V
Output Connector Qty: 6
Power Capacity (VA): 1440 VA, 1500 VA
Power Device Features: Audible alarm , Automatic Voltage Regulation (AVR) , LCD display , LED indicators
Power Provided: 1 kW, 1000 Watt
Surge Suppression: Yes
UPS Output Waveform: Sinewave
UPS Technology: Line interactive
Voltage Provided: 120 V, AC 120 V
Voltage Provided Margin: ± 5%
Voltage Required: AC 120 V

Slot Provided
Free Qty: 1
Total Qty: 1
Type: SmartSlot

Software
Type: Drivers & Utilities

Dimensions & Weight
Depth: 18 in, 45.7 cm
Height: 3.5 in, 8.9 cm
Weight: 28.64 kg, 63.1 lbs
Width: 17 in, 43.2 cm

Service & Support
Type: 3 years warranty

Cable Details
Included Qty: 1



Form Factor: Integrated

Dimensions & Weight (Shipping)
Shipping Depth: 23.7 in, 60.3 cm
Shipping Height: 25.1 cm, 9.9 in
Shipping Weight: 31.91 kg, 70.3 lbs
Shipping Width: 23.4 in, 59.4 cm

Environmental Standards
ENERGY STAR: Yes

General
Product Type: UPS
Subcategory: UPS

Run Time Details
Load Type: Full load
Run Time (Up To): 7
Run Time (Up To): 7.2



Load Type: Half load
Run Time (Up To): 25.8
Run Time (Up To): 26



Load Type: 50 Watts
Run Time (Up To): 335



Load Type: 100 Watts
Run Time (Up To): 190



Load Type: 200 Watts
Run Time (Up To): 92



Load Type: 300 Watts
Run Time (Up To): 56



Load Type: 400 Watts
Run Time (Up To): 37



Load Type: 500 Watts



Load Type: 600 Watts
Run Time (Up To): 19



Load Type: 700 Watts
Run Time (Up To): 14



Load Type: 800 Watts
Run Time (Up To): 11



Load Type: 900 Watts
Run Time (Up To): 9



Load Type: 1000 Watts

Service & Support Details
Component: Batteries

UPS
Batteries Qty: 1
Battery Technology: Lead acid
